Aline SABRE BAH750-1A High Head Drainage Pump 1HP 240V
30-day returns on unused stock in original packaging. Incorrect sizing without prior consultation is at the buyer's expense.
Overview
The Aline SABRE BAH750-1A is a 0.75kW Single Phase submersible high head drainage pump. A high-head drainage pump for stormwater and lightly contaminated water where extra lift is needed. Automatic operation with a built-in float switch, starting and stopping on water level. It delivers up to 28m of head and 220 litres per minute.
Highlights
- SABRE high head drainage submersible pump
- 0.75kW / 1HP, Single Phase 240V
- Automatic operation
- Maximum head up to 28m
- Maximum flow up to 220 L/min
- Cast iron construction
- Australian supported by Aline
How the High Head Drainage Pump Works
A high-head drainage pump for stormwater and lightly contaminated water where extra lift is needed.
Specifications
| Specification | Details |
|---|---|
| Model | BAH750-1A |
| Supplier Code | 152100304 |
| Pump Type | Submersible High Head Drainage Pump |
| Motor Power | 0.75 kW (1HP) |
| Voltage | 240V |
| Phase | Single Phase |
| Operation | Automatic |
| Maximum Head | 28 m |
| Maximum Flow | 220 L/min |
| Construction | Cast iron |
| Manufacturer | Aline (SABRE) |
Performance figures are indicative from the SABRE pump curve. Confirm head and flow at your duty point before ordering.
Applications
- High-lift stormwater drainage
- Dewatering with long vertical runs
- Pit and sump emptying
- Water transfer
Installation Notes
- Electrical connection must be carried out by a licensed electrician.
- For manual models, fit an external float or control panel to switch the pump.
- A lifting chain and guide rail or free-standing base should be matched to the pit.
- Confirm solids type, head and flow against the specifications above before ordering.
What's Included
- 1 x Aline SABRE BAH750-1A High Head Drainage Pump with built-in float switch
Warranty
Backed by Aline's Australian manufacturer's warranty, with local support.
Need Assistance or Ready to Order?
Our team can help you match the right pump to your pit, solids type and duty. Contact us at sales@waternex.com.au or call 1300 930 847 for advice and support.
Downloads
Specification sheets and certificates for this product.
