REEFE EPS2T Digital Pressure Switch 415V Three Phase
30-day returns on unused stock in original packaging.
Overview
The EPS2T is the three phase version, rated to 415 volts and 4.4 kW with a 12 bar maximum pressure and a cut out range to 12 bar. It carries the same current monitoring and dual pump capability as the EPS2.
Highlights
- Electronically controlled pressure switch with an integrated digital manometer and transducer
- Push button controls and a clear digital display
- Cut in and cut out pressures are easily adjustable
- Inbuilt pressure transducer for accurate pressure detection
Features
- Run dry protection by minimum pressure detection
- Fast cycling protection if the pressure tank fails
- Pressure sensor failure isolates the pump
- Light indicators for visual alarms and power status
- Pressure settings in either bar or psi
- Run dry protection by minimum current, in addition to minimum pressure
- Overload alarm on amperage overload
- Can operate two pumps together in duty alternating or duty assist mode
- Measures instantaneous current consumption in amps
Construction
- Maximum liquid temperature 40 C
- Maximum ambient temperature 50 C
- Ingress protection IP55
- Certified to AS/NZS 4020 for use with potable water
Applications
- Constant pressure supply in domestic and irrigation systems
- Automatic operation of submersible and dry mount pressure pumps
- Replacement for an old style mechanical pressure switch
Specifications
| Model Number | EPS2T |
| REEFE Product Code | 28421 |
| Power Supply (V) | 415 |
| Current Draw (A) | 10 |
| Motor Range (kW) | 4.4 |
| Maximum Pressure | 12 bar |
| Input and Output | No |
| Cut In Range | 0.5-11.5 bar |
| Cut Out Range | 1 - 12 bar |
| Pressure Differential | Min. 0.5 bar Max:11.5 bar |
| Factory Preset Cut In and Out | 3 bar / 4 bar |
| Cable Length | Optional with 1.5m Cable, QP or 3PS, 10A or 15A |
| Inlet and Outlet | 6mm |
| Shipping Weight | 0.9 kg |
| Brand | REEFE |
What Is Included
- 1 x REEFE EPS2T digital pressure switch
Warranty
REEFE provides a 2 year warranty on this product.
